Beiyi Hydraulic Round Pile Breaker/Hydraulic Pile Cutter

Beiyi Pile Breaker is an efficient, economical and advanced system for cutting concrete outcrops and foundation piles.The modular design makes the pile breaker extremely easy to crush concrete piles of different diameter at the jobsite.Additionally, each module contains a separate cylinder and brazing rod system. With the help of hydraulic pressure, the oil cylinder drives the brazing rod to squeeze the pile.Thanks to this way of working, no cracks and damage will be caused to the pile and reinforcement underground.
When it comes to the efficiency of our pile crusher, the traditional way of crushing normally takes one day for 2-3 pile. However, the beiyi pile breaker break 1 pile just need 4 minutes and only 10 minutes for round hydraulic pile breaker.while keeping intact the rebar and structural integrity of the piles.Also, thanks to the independent modular structure, air and noise pollution in construction sites will be reduced significantly.

Details
Modular Design
The modules can be increased or decreased according to the diameter of the broken pile head，which is convenient for transportation and combination.through the combination of different numbers of modules,the pile heads of different diameters can be cut

Drill rod
The tapered top design avoids the accumulation of soil in the guide flange，the sticking，deflection and easy breakage of the steel brazing.

Rotating disc
Remote operation，360° all-around observation，easy operation and safe operation.

Support customization Choose what you need

In order to solve the problems of limited site construction，too many piles heads and too slow efficiency，Beiyi Machinery focuses on the development of a variety of pile breaking tools to make construction one step faster！

Beiyi hydraulic pile breaker can break down foundation piles quickly and accurately，and keep the steel bars on the ground completely，more importantly，no noise is generated during operation，it is a device with powerful functions，safe operation，quiet static pressure and high cost performance.

Module Number	4	8	9	10	11	12	13	14	15	16	17	18
Combination total weight	1600	2640	2970	3300	3630	3960	4290	4620	4950	5280	5610	5940
Pile diameter range	400-600	600-800	800-1000	1000-1150	1150-1300	1300-1500	1500-1650	1650-1800	1800-1970	1970-2200	2200-2360	2360-2500
For Excavator	20-30			30-40				Hydraulic system/pump station

Features
· Low cost,high efficiency,low noise pile cutting
· Reliable quality and long life,Simple operation
· Modular design
· Can be hung on excavators cranes,telescopic booms and other construction machinery
· The supporting hydraulic station can be operated remotely
